|Model||HPC - 20|
|Winch Speed (Up/down)||m/sec||0.28/0.30|
|Gross Vehicle Weight(Laden/Unleden)||Kgs||39300/19300|
|Static Weight on Front Axe (Laden/Unladen)||Kgs||35340/6770|
|Static Weight on Rear Axle (Laden/Unladen)||Kgs||3960/12530|
||12.00 x20,16 PR|
|Model||AL 412 TAC3|
|Rating / Speed||HR/RPM||136/2400|
|Bore x Stroke||mm x mm||108 x 121|
|Type||Power shift with Torque Converter|
|Dimensions||Front over hang||mm||750|
|Rear over hang||mm||950|
|Turning circle radius||mm||4950|
A heavy duty 37 Ton static load capacity Drive Axle is fitted.This axle is rigid mounted to the chassis. A pneumatic braking system is fitted to the Drive Axle with integral parking brake.
Heavy Duty Vane Pump driven by Transmission Power take-of is provided. Suction strainer and Return line. filter provided to ensure self cleaning system for long reliable pump,valves,cylinders and seal life.Fine metering control valves provided for smooth and accurate control functions. Integral pressure relief valve prevents system overload.
Monocoque type with integral hydraulic and fuel tanks.Designed for strength, maximum torsional rigidity and for long term reliability.
Available in both 2-stage and 3-stage telecopic type MIG welded from hi-tensile steel plates. Slides on low friction oil impregnated nylon pads and precisely assembled fo perfect co-axiality.
The Rear Axle has a full time power steering with hydrostatic steering system and heavy duty balanced cylinder. Steering Axle fabricated from high stregth steel and stub axles are of forged single piece alloy steel. The steering axle provides an articulation that ensures positive wheel contact on uneven surfaces..
